Specifications:
Application: Charger Controller, Voltage Controller, Lighting Controller, Solar System Controller, Solar Working Station
Battery Voltage: 12V/24V AutoRated current: 100A
Max. PV voltage: 36V(24V Battery);18V(12V battery)
Max. PV input power: 750W(12V) / 1200W(24V) for 60A/100A Solar Controller
Charging Mode: MPPT+PWM
MPPT, or maximum power point tracker
Pulse-width modulation (PWM)
- Rated voltage: 12/24V
- Rated current: 100A
- Max. PV input power: 750W(12V) / 1200W(24V)
- System voltage: 12 / 24V adaptive
- Rated charging current: 100A
- Solar photovoltaic voltage :12V battery with 18V solar panel, 24V battery with 36V solar panel
- Full Voltage Value : Lithium Battery (12.2V) | B02 Colloidal Battery (14.2V) | B03 Open Cell (14.6V)
- Floating Charge Voltage : 13.7 V ( Default, Adjustable )
- Discharge cut-off voltage::10.7 V ( default, adjustable )
- Discharge recovery voltage: 12.6 V ( default, adjustable )
- Standby current :10mA
- USB Output : 5V / 2A MAX
- Operating temperature:- 35 - 60
Package Includes：
1 x Solar Panels Battery Charge Controller
1 x User Manual(English)
